Hanging Die Arm

The arm itself and the support in Model RC can be used separately.
The hanging lengthen(Y) of Model RD should be less than the height between the plate and the ground.

Send Inquiry

Product Introduction

MODEL RD (HANGINF)

product-1658-534

The arm itself and the support in Model RC can be used separately.

The hanging lengthen(Y) of Model RD should be less than the height between the plate and the ground.

Model	Model of support	Length of the Die (L)	Capacity (kg)	Total Length (A)	Dimension Of Support			Hole Pattern for Installation	Roller Q'ty	Dimension After Folding
					D	B	H			X	Y
RD-580A	RD-12A	500	800	550	52	115	118	A Type	5	145	630
RD-760A		700	600	750					7		830
RD-880A	RD-14A	800	800	850			138	B Type	8	165	950
RD-990A	RD-16A	900	900	950			158		9	185	1070

RD-05125A	RD-14HA	500	1250	550	52	115	138	B Type	7	165	655
RD-05160A	RD-15HA		1600				148			175	665
RD-05200A	RD-16HA		2000				158			165	675
RD-07125A	RD-14HA	700	1250	750			138		9	165	855
RD-07160A	RD-16HA		1600				158			185	875
RD-07200A	RD-18HA		2000				178			205	895
RD-08125A	RD-16HA	800	1250	850			158		10	185	975
RD-08160A	RD-18HA		1600				178			205	995
RD-08200A	RD-19HA		2000				188			215	1005
RD-09160A	RD-18HA	900	1600	950			178		11	205	1095
RD-09200A	RD-20HA	900	2000	950			198		11	225	1115

The hanging type design allows the Die Arm to be suspended on the side of the press when not in use. This method eliminates the need for disassembly, enabling quick and convenient storage. It helps keep the work area organized while ensuring the Die Arm remains readily accessible-ideal for production environments that prioritize quick die changes.
